YSS- REAR SHOCK ABSORBER
From the brand YSS, international quality standards, preload settings can be adjusted up to 7 levels to accommodate different driver usage patterns. to be able to support Vibration at full efficiency
ROUSING FUNCTION
STILL HAVE A LOT TO OFFER
FUEL TANK
SPORT DOUBLE SEAT
11 liter oil tank, fierce design
with sharp lines with Kevlar pattern on the top of the body
2-section seat, sporty shape,
designed to accommodate the ergonomics of the rider and the stacker.
SPECIFICATION
Engine
Dimension
Electrical
| Engine | 4 strokes, SOHC, Hyper . 4 valves |
| Cylinder volume: | 164.6 cc |
| Max Power: | 19.2 bhp @ 10500 rpm |
| Max Torque: | 15.0 n.m. @ 7500 rpm |
| Cooling System: | Liquid-cooled |
| Width x Length x Height: | 747 x 2,020 x 1,145 mm. |
| Wheelbase: | 1,350 mm. |
| Seat Height: | 815 mm. |
| Ground Clearance: | 159 mm. |
| Net weight: | 155 kgs. |
| Headlight: | LED |
| Tail Light: | LED |
| Turn light: | LED |
| Battery: | 12V 6.3Ah |
| Speedometer: | Full LED Digital Meter with Soft Touch Technology |
| Bore x Stroke: | 59.7 x 58.8 mm. |
Wheel & Tire
Brake
| Starting System: | Electric |
| Ignition: | TCI (Transistor controlled ignition) |
| Fuel System | GPX-FI |
| Ratio: | 11.5: 1 |
| Gear system: | 6 speeds |
| Front / rear wheel: | 17 inches |
| Front tire size: | 100/80 (Tubeless) |
| Rear tire size: | 140/70 (Tubeless) |
| Front brake: | Disc brake |
| Rear brake: | Disc brake |
| ABS | Dual Channel |
Suspension
Frame & Others
| Front shock absorber: | Upside down |
| Rear shock absorber: | YSS 7 levels adjustable |
| Body structure: | Trellis frame |
| Fuel capacity: | 11 Liters. |
| Chain: | O-Ring |
